Four roll hydraulic bending machine HDLW12HXNC-60 * 2500
The four roll plate rolling machine has excellent performance, easy operation, and high efficiency, and is widely used in industries such as boilers, shipbuilding, petrochemicals, aviation, hydropower, decoration, and metal structures. Can be used to roll metal sheets into cylindrical, conical, or cylindrical parts. The advantage of this equipment is that it can complete the pre deformation of both ends of the sheet metal and roll cylindrical and curved workpieces within a certain range without the need for auxiliary devices during a single feeding process. It also has the function of pre bending the metal sheet metal ends, with small remaining straight edges. Due to the rotary encoder on the driving roller, the lifting and lowering of the lower and edge rollers are measured by an encoder. Therefore, after appropriate program calibration, this machine can roll irregular shaped cans.
1. Maximum processing thickness of equipment: 60mm
2. Maximum processing width of equipment: 2500mm
3. Equipment rolling speed: about 4m/min
4. The synchronization accuracy of the lower and side rollers of the equipment is maintained at ± 0.05mm
