Location：|
Eyepiece |
Wide feld WF10X(feld number:$22mm) |
||
|
Infinity planachromatic objective |
Equipped with bright feld objectives |
PLL10X0.25(Work distance):5 mm |
|
|
PLL20X0.40(Work distance):8.80 mm |
|||
|
PLL50X0.70(Work distance):3.68 mm |
|||
|
PLL100X0.85(Dry)(Work distance):0.40 mm |
|||
|
Equipped with bright & dark fieldobjectives |
PLL5X0.12 BD(Work distance):8.05mm |
||
|
PLL10X0.25 BD(Work distance):7.86 mm |
|||
|
PLL20X0.40 BD(Work distance):7.23mm |
|||
|
PLL50X0.70BD (Work distance):2.50mm |
|||
|
Eyepiece tube |
Inclination angle is 45"and interpupillary distance is 53~75mm. |
||
|
Focus system |
Coaxial coarse/fne focus, with tension adjustable, minimum divsion of fine focusing is 2ym. |
||
|
Nosepiece |
Quintuple(Backward ball bearing inner locating) |
||
|
Stage |
Mechanical stage overall size: 242mmX200mm and movng range : 30mmX30mm. |
||
|
Rotundity and rotatable stage size: maximal measurement is $130mm and minimal clear aperture is less then 中20mm |
|||
|
lllumination system |
DZ-8 |
6V30W halogen and brightness enable control |
|
|
DZ-8MA |
12V50W halogen and brightness enable control |
||
|
Integrated feld diaphragm , aperture diaphragm and puller type polarizer. |
|||
|
Equipped with frosted glass and yellow ,green and blue filters |
|||
|
Optional accessories |
Eyepiece |
Dividing eyepiece 10X(Ф22mm) |
|
|
Objective |
DZ-8 |
5X、40X、60X、80X、100X Equipped with bright feld objectives |
|
|
DZ-8MA |
40X60X80X、100X Equipped with bright & dark field objectives |
||
|
CCD Adapter |
0.5X、1X |
||
|
Camera |
USB output 1.3M,3.0M,5.0M,10M pixel
|
||
|
video output 380/520 TV line
|
|||
|
Digital camera adapter |
CANON(EF) NIKON( F) |
||
