Handheld spectrometer is a spectral analysis instrument based on XRF (X-ray Fluorescence) spectral analysis technology, mainly composed of X-ray tube, detector, CPU, and memory. Due to its portability, high efficiency, portability, and accuracy, handheld spectrometer has a wide range of applications, including power, petrochemicals, archaeological metal processing, pressure vessels, waste material recycling, aerospace, geological exploration, mining surveying, ore sorting, mineral trade, metal smelting, environmental monitoring, soil monitoring, toys, clothing, shoes and hats, electronic products, and many other fields.
Main technical parameters
1. Weight: Net weight of the instrument 1.3Kg
2. Working temperature: -10 ℃~+50 ℃
3. Appearance: Integrated design of instrument host screen, dimensions: 242mmx289mmx83mm
4. Excitation source: High performance miniature X-ray tube, tungsten target, tube power 2W, matched tube voltage 35KV, tube current 50 μ A
5. Detector: High precision, high sensitivity, and high resolution silicon semiconductor detectors are used, and Peltier semiconductor constant temperature cooling is employed
6. Scope of analysis:
Alloy modes: 23 elements including Ti, V, Cr, Mn, Fe, Co, Ni, Cu, Zn, Zr, Nb, Mo, Pd, Ag, Cd, Sn, Sb, Hf, Ta, W, Re, Pb, Bi, etc
Precious metal modes: Ti, Cr, Mn, Fe, Co, Ni, Cu, Zn, Ga, Ge, Zr, Ru, Rh, Pd, g, Cd, In, Sn, Sb, w, 0s, lr, Pt, Au, Pb, Bi26 elements
Three way catalyst modes: 28 types of catalysts including Ti, v, Cr, Mn, Fe, Co, Ni, Cu, Zn, Se, Sr, Zr, Nb, Mo, Rh, Pd, Ag, Cd, Sn, Sb, Ba, Ce, Hf, Ta, W, Pt, Pb, Bi, etc
Geochemical ore patterns: 25 elements including Ti, V, Cr, Mn, Fe, Co, Ni, Cu, Zn, As, Se, SrY, Zr, Nb, Mo, Ag, Cd, Sn, Sb, w, Hg, Pb, Bi, Th, U, etc
7. Element content detection range: 0.001% to 100.00%
8. Operating System: Linux Operating System
9. Intelligence: Users can set the brightness of the display screen, font size, whether screen rotation is allowed, button sound, etc. according to their own usage habits, and even set warning sound requirements for each stage of testing
10. Quantitative method: Basic parameter method (FP) combined with empirical coefficient method, blind sample testing has better results
11. Digital display control: 800 * 480 (WVGA) LCD capacitive touch screen operation, supports direct screenshot operation, and the detection results can be clearly seen even under direct sunlight; Support physical button control
12. Safety and reliability: Compliant with IP54 standards, with dustproof and waterproof performance: Passed the 4-foot (1.2m) high-altitude drop test of the US military standard MIL-STD810G; Large area radiators can provide ideal reliability and stability even in high temperature environments; The X-ray activation warning light flashes; Back scattered infrared protection, automatic stop without sample, preventing misoperation
13. Filter: Built in 1 set of filters
14. Power supply: Rechargeable lithium battery, which can display the battery level and can be used continuously for 4-6 hours. It can be powered by a rechargeable lithium battery or an AC adapter
15. Data storage: 4GB embedded storage, external 1G SD card, expandable storage capacity, data arranged in units of year, month, and day, can quickly search for data, can store hundreds of thousands of test results, can use WiFi or Bluetooth for network sharing
16. Data transmission: 3 USB interfaces, can be transmitted through SD card, USB flash drive, USB cable or optional WIFI, Bluetooth, cloud drive. The report can be in PDF or Excel format, including element content, spectrum, etc., and there are multiple templates to choose from
